Product Detail

Model No.: CR884 Series

Production Capacity: 20sets/month

Delivery Date: 40 days

Type: Flexographic Printer

Usage: Others

anilox roller: Ceramic anilox roller

Means of Transport: Ocean

Packing: as required

Plate: Letterpress

Color & Page: Multicolor

Brand Name: Changhong

doctor blade: one side type

4 Color Flexographic Printing Machine
1.high efficiency
2. PE, PP, HDPE, film printing
3. with ceramic anilox roller, doctor blade

1. Machine Frame: cast iron, vibration-free at high speed operation , accurate color register, high quality can be sure long time use;

2. Adopts Taiwan motor, Taiwan inverter, save power, smooth running;

3. Anilox roller: Ceramic roller and doctor blade by 250-800Lpi, Japan branad;

4. Ink: Adopt the automatic circle system, running ink by singles mall motor

5. Unwind EPC: adopt the high quality automatic EPC controller device;

6. Unwind and rewind way: adopt the magnetism and Auto tension controller

7. Ink way: our company has special design for the doctor blade device with the ink pump can suck the ink automatically

8. Up and down plate: Adopt the hydraulic pressure rising and down the printing plate automatically

9. Roller: adopt the Germany special steel processing, and through the special technique treatment, and plating thickness of 10silk protective layer of hard chromium;

10. Traction Rollers: Aluminum guide roller get treatment of rigid oxidation, moving balance, motionless balance.

11. Drying device: Use blower and heating double drying device, Constant remperature control device set inside the heating device, control every unit, cool blower fixed shape;

12. Machine body: thick wall (75mm), longer bridges, thick base, making the machine more stable.

Series	CR Series
Machine model	CR884-600	CR884-800	CR884-1000	CR884-1200	CR884-1400	CR884-1600
Printing width Item	600mm	800mm	1000mm	1200mm	1400mm	1600mm
Printing color	4 color (PC: 4+0; 3+1; 2+2)
Printing length	7.5" -40" /7.5" -50" /7.5" -60" /7.5" -70" /7.5" -80"
Printing plate lifting system	Hydraulic press control
Mechanical speed	90m/min
Printing speed	70m/min
Anilox cylinder	ceramic anilox roller, doctor blade
Register precision	Longitude: ± 0.15mm Transverse: ± 0.15mm
Rewinder/Unwinder DIA	ø 800mm
Master motor	3.7KW
Rewinder motor	1.5 KW		2.2 KW		3.0 KW
Electrical header	14KW	16KW	20KW	22KW	24KW	26KW
Blower of header	0.95KW× 4	0.95KW× 4	0.95KW× 6	0.95KW× 6	0.95KW× 6	0.95KW× 6
Blower of nature wind	75 W× 8	75 W× 8	75 W× 12	75 W× 12	75 W× 12	75 W× 12
Master frequency converter	transducer Japan
Bearing	Japan(NSK)
Unilateral bearing	ASNU (Germany)
Master power	24KW	26KW	28KW	30KW	35KW	40KW
Dimension (L× W× H)	4.8m × 2.0m × 2.5m	4.8m × 2.2m × 2.5m	4.8m × 2.4m × 26m	4.8m × 2.6m × 2.6m	4.8m × 2.8m × 2.7m	4.8m × 3.0m × 2.7m
