Printing Embossing Tissue Paper Napkin Machine from China manufacturer - Rui'an Changhong Printing Machinery Factory

Printing Embossing Tissue Paper Napkin Machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Packing: as required

Plate: Letterpress

Color & Page: Multicolor

Brand Name: changhong

Production Capacity: 20 sets/month

Delivery Date: 40 days

Type: Flexographic Printer

Usage: Others

printing machine: printing machine

1 Speed 560 sheet/min
2 Embossing Printing Max. 8 colors
3 Easy operation
4 CE
5 Auto counting Calender unit

High Speed 1/4 Fold Printing Embossing Tissue Paper Napkin Machine

Featuring low price, small occupancy area and good flexibility, it is suitable for printing special tissue paper.
1. In-feed and Out-feed system provided to maintain tension & good registration.
2. Auto Stop for web break.
3. Helical Gear for smooth running and long life.
4. All rolls are dynamically balanced and hard chrome plated...

ModelItem	CH884-330MZ	CH884-500MZ	CH884-800MZ		CH806-330MZ			CH806-500MZ		CH806-800MZ
Material	17g/m²-80g/m² Tissue paper
Material width	400mm	600mm	900mm		400mm			600mm		900mm
Printing color	Four color	Four color	Four color		Six color			Six color		Six color
Material specifications	330×330	330×330 450×450 600×600	330×330 450×450 600×600 900×900		330×330			330×330 450×450 600×600		330×330 450×450 600×600 900×900
Register precision	Longitude:±0.20mm Transverse:±0.20mm
Printing length	200-330	200-600	200-900		200-330			200-600		200-900
Anilox cylinder	80-160DK (German made Titanium roller)
Printing plate lifting system	Pneumatic/Hydraulic press control
Mechanical speed	100m/min
Printing speed	80m/min
Output (sheet/hr)	14000	14000 10000 8000		14000 10000 8000 5100		14000		14000 10000 8000	14000 10000 8000 5100
Rewinder/Unwinder DIA	ø 600mm/ø800mm
Master electric machinery	2.2KW	3KW		3.7KW		3KW	3.7KW		4KW
Rewinder motor	1.1KW	1.1KW		1.5KW		1.1KW	1.1KW		1.5KW
Dryer	0.75KW	0.75KW		1.1KW		0.75KW	0.75KW		1.1KW
Powder brakes	2.5Kg	5Kg		5Kg		2.5Kg	5Kg		5Kg
Paper magnetic powder clutch	5Kg	5Kg		10Kg		5Kg	5Kg		10Kg
Tension sensor	2-10 Kg	2-15 Kg		2-20 Kg		2-10 Kg	2-15 Kg		2-20 Kg
Aridity Mode	6KW	8KW		11KW		8KW	10KW		14KW
Master power	10KW	12KW		15KW		12KW	15KW		20KW
Weight	5010Kg	5350 Kg		6150 Kg		5960 Kg	6350 Kg		7350 Kg
Dimension (L×W×H)	3.85m × 1.55m × 2.6m	3.85m × 1.7m × 2.65m		3.85m × 2.0m × 2.7m		4.0m × 1.6m × 3.1m	4.0m × 1.8m × 3.2m		4.0m × 2.2m × 3.3m
